Wood chipper DK-30, wood shredder, 2 in 1

Wood shredder, Wood chipper DK-30

The F-Z Ukraine company presents a unique DK-30 crushing complex, which allows you to effectively grind wood waste (cards, scraps, boards up to 140 mm wide, logs up to Ø 120 mm) into a fine fraction of 2-5 mm (sawdust). This fraction is ideal for further granulation or briquetting, use as fuel in boilers, or for the production of chipboard and other products.

Main advantages:

• 2-in-1 complex: DK-30 combines the functions of a shredder and a crusher, which allows you to significantly save on equipment and costs.
• Efficiency: Obtaining fine sawdust in one pass without the need for additional equipment.
• Wide range of applications: Ideal for the production of fuel, chipboard, pallet bars, etc.

With the DK-30 from F-Z Ukraine, you will be able to significantly reduce costs of equipment, time and electricity, obtaining a high-quality final product in one work cycle.

Technical characteristics of the crushing complex type DK-30 for crushing wood waste:

Type: Stationary

Drive: electric motor — 30kWx1000 rpm

Disc:

- with 3 knives and 1 counter knife

- diameter 500 mm

- thickness 40 mm

- rotation frequency of 1000 rpm

Drum:

- 64 hammers

- sieve 1 pc. (sieve shoes 5 mm. — cell diameter to order)

Automatics:

- control panel with automatic regulator

Unloading of raw materials:

- pneumatic through a cyclone: ​​5.5 kW x 3000 rpm,

Size:

- length 2450 mm

- height 1400 mm

- width 1300 mm

Weight: 900 kg.

Output fraction: sawdust 2-5 mm.

Productivity 500-700 kg. / time at humidity up to 60%
