Wood Shredder 2 in 1 DK-50

Wood Shredder 2 in 1 DK-50

Product description:

The DK-50 series wood chipper is a universal disc-drum type chipper that offers an efficient solution for wood and waste processing. This high-performance device combines the ability to grind large waste into small fractions, which makes it ideal for further granulation, briquetting, use in heating boilers or the manufacture of various products from sawdust.

Technical characteristics of the DK type crushing complex for crushing wood waste:

Type: stationary

Drive: electric motor - 45-55 kWx1000 rpm

Disc:

 - with 3 knives and 1 counter knife

 - diameter 800 mm

 - thickness 40 mm

 - rotation frequency 1000 rpm

Hydraulic system:

 - the mud hopper has two tightening rollers with teeth: width 230 mm x 280 mm.

 - each roller has a separate hydraulic drive and stress shock

 - the system is equipped with an oil flow regulator with a pressure compensator, which allows you to adjust the feed rate of raw materials.

Drum:

 - with 86 hammers

 - sieve 1 pc. (sieve cells 5 mm. - different sizes of cells are possible)

 - counter knives 22 pcs.

Automatics:

 - a control panel with an automatic regulator of voltage and hydraulics

Unloading of raw materials:

 - pneumatic through a cyclone: ​​5.5 kW x 3000 rpm,

Overall dimensions:

 - length 2450 mm

 - height 1400 mm

 - width 1300 mm

Weight: 1400 kg.

Output fraction: sawdust 2-5 mm.

Available at the warehouse in Lviv and to order

Productivity 1000-1500 kg/hour at humidity up to 60%

Advantages:

• Versatility: The ability to grind a wide range of wood waste and obtain different fractions
• Efficiency: Productive work with large waste and precise grinding to the required fraction
• Wide range of applications: Ideal for the further use of sawdust in granulation, briquetting, fuel-mechanical systems and for the manufacture of wood products

Wood crusher DK-50 will help you to optimize wood processing processes, increase the efficiency of your production and provide quality material for various needs. Order DK-50 and turn your wood waste into a valuable resource!
